TCD 2015 V6

Modern water-cooled four stroke 6-cylinder V-engine.
Water-cooled turbocharger and exhaust manifolds.
PTOs gear driven.
Modern injection system with mechanical governor.
Electronical governor for gen set application.
Charge-air-cooler by engine cooling liquid.
Innovative DEUTZ Multi-Parallel-Cooling System.
Compact design.

Technical data
Emission norms EU III, EU II
Number of cylinders 6
Bore 132 mm5.2 in
Stroke 145 mm5.7 in
Displacement 11.9 l726 cu in
Maximum nominal speed 2100 rpm
Power output 360 kW483 hp
at speeds 1900 rpm
Max. torque 1990 Nm1468 lb/ft
at speeds 1300 rpm
Length 832 mm32.8 in
Width 932 mm36.7 in
Height 1169 mm46 in
Weight 1020 kg2249 lb
Download data sheet (PDF-file)
