BF 6 M 1015 M

Modern water-cooled four stroke 6-cylinder V-engine.
Water-cooled turbocharger and exhaust manifolds.
PTOs gear driven.
Modern injection system with mechanical governor.
Electronical governor for gen set application.
Charge-air-cooler by engine cooling liquid.
Innovative DEUTZ Multi-Parallel-Cooling System.
Compact design.

Technical data
Number of cylinders 6
Bore 132 mm5.2 in
Stroke 145 mm5.7 in
Displacement 11.9 l726 cu in
Propulsion engines LG A 214 kW287 hp
Propulsion engines LG B 240 kW322 hp
Specific fuel consumption 213 g/kWh0.35 lb/hph
Length 1379 mm54.3 in
Width 1316 mm51.8 in
Height 1159 mm45.6 in
Weight 1080 kg2381 lb
Download data sheet (PDF-file)
